Technical specifications
◆ Ranges of tee: 710mm－1200mm
（710mm-800mm-900mm-1000mm-1200mm）
◆ Ranges of cross: 710mm－1200mm
（710mm-800mm-900mm-1000mm-1200mm）
Ranges of elbow（n×11.25°）: 710mm－1200mm
（710mm-800mm-900mm-1000mm-1200mm）
◆ Ranges of application: PE，PP and PVDF
◆ Working voltage: ～380V ±10%，50Hz
Total power: 73.5 kW , including: planing tool motor: 4 kW, heating plate: 62 kW, hydraulic unit motor: 7.5 kW
◆ PTFE coated heating plate, high accuracy temperature controller, difference in heating plate surface temperature ≤±5°; PLC control system;
◆ Environment temperature: －10° ～ 45°
◆ Electronic count-down timer for heating and cooling time.
◆ Whole machine consists of four parts: basic frame ( including: heating plate, planing tool, and hydraulic system), elbow clamps, tee clamps, and cross clamps
Features
1. Suitable for manufacturing PE PP PVDF elbows, Teem, Cross, Y-shaped (45 and 60) accessories in the workshop
2. The overall structure, only need to choose different special fixtures when manufacturing different accessories.
3. Consists of a basic frame, hydraulic unit, trimmer, heater and electrical control unit.
4. Removable PTFE coated heating plate with independent temperature control system.
5. The electrical unit provides compression force for the welding machine.
6. The hydraulic unit provides compression machinery for the welding machine
7. Low starting pressure ensures reliable welding quality of small pipelines.
8. Including temperature controller and timer, easy to understand time and temperature.
ACCESSORIES LIST
| No | Name | Unit | Qty | Remark |
1 | Main machine | set | 1 | |
2 | Electrical control box | set | 1 | |
3 | Tee clamps (inserts included) | set | 1 | Spec: Φ710~Φ1000 |
4 | Elbow clamps (inserts included) | set | 1 | Spec: Φ710~Φ1000 |
5 | Screws for main clamp | set | 1 | Outer hexagonal screw: |
6 | Elbow main clamp locking plate | pcs | 4 | |
Accessories with machine | ||||
1 | Hammer | pcs | 1 | |
2 | Screws for inserts | set | 1 | |
3 | Special location handle | pcs | 1 | |
4 | Spare blade | pcs | 2 | |
5 | Location pin | pcs | 6 | 4 short 2 long |
6 | 24mm box wrench | set | 1 | |
7 | inner hex wrench | set | 1 | Spec: 4~14 |
8 | 250mm adjustable spanner | pcs | 1 | |
9 | 24mmcombination spanner | pcs | 1 | |
10 | Open end wrench | pcs | 1 | Spec: 32~36 |
11 | cross screw driver | set | 1 | Spec: 150mm, 250mm |
12 | Warranty card | pcs | 1 | |
13 | Operation manual | pcs | 1 | |
14 | Adjustment cushion | set | 8 | |
15 | Planing limit box | pcs | 1 | |
PACKING LIST
| Item | Dimension with packing（mm） | N.W（kg） | G.W（kg） | Remark |
1 | 3200×2500×1900 | 9000 | 9990 | Basic frame |
2 | 920×720×1110 | 400 | 500 | Hydraulic unit |
3 | 1500×1450×1450 | 3000 | 3800 | Elbow clamps |
4 | 2040×2000×1500 | 5000 | 5900 | Cross clamps |
5 | 820×670×1150 | 100 | 150 | Electric box |
Total | 25.9CBM | 17500 | 20340 |
Our services
Pre-sale services:
1. Providing professional technical support.
2. Send the product catalog and instruction manual.
3. If you have any question PLS contact us online or send us email, we promise we will give you a reply at the first time!
4. Personal call or visit are warmly welcome.
Sale of services:
1. We promise honest and fair, it's our pleasure to serve you as your purchasing consultant.
2. We guarantee punctuality, quality and quantities strictly implement the terms of contract...
After-sales service:
1. Where to buy our products for one year warranty and life long maintenance.
2. 24-hour telephone service.
3. A large stock of components and parts, easily-worn parts.
