Product Description
The SDD450 Butt Weld Pipe Fitting Machine For Hdpe Pipes is an advanced and efficient tool for welding PE pipes. It offers good temperature control methods that guarantee precise and consistent heating, ensuring the best weld quality and integrity.
One of the great features of this machine is its constant temperature control method, which maintains a stable and uniform temperature throughout the welding process. This means that you can rely on this machine to provide an accurate and reliable result each time.
In addition to constant temperature control, the machine also offers manual single and double temperature control, giving you complete control over the welding process. You can adjust the temperature according to the size and thickness of the pipes, ensuring perfect results every time.
Another impressive feature of this machine is the independent temperature control of the heating mirror. This allows you to adjust the temperature of the heating mirror separately from the socket, giving you even greater control over the welding.
To ensure safety and precision, the machine is equipped with temperature adjustment, temperature display, overheat alarm, and automatic retrieval of ambient temperature. These features not only make the welding process safer but also help to reduce the risk of defects.
Note:
(1) The electric heating plate plug should be connected to the electric box before the machine is powered on. It is strictly forbidden to connect the electric heating plate plug to the electric box after the machine is powered on;
(2) The sectional area of the power supply line of the machine shall not be less than 1.5mm2 copper core wire;The surface temperature of electric heating plate should be higher than 200 ℃;
USES and features:
1 Suitable for butt welding of plastic pipes and fittings made of PE, PP and PVDF material.
2 SDD450 Butt Weld Pipe Fitting Machine For Hdpe Pipes Consists of basic frame, hydraulic unit, planing tool, heating plate, basket & optional parts.
3 Removable PTFE coated heating plate with high accurate temperature control system.
4 Electrical planing tool.
5 Reliable structure design, suitable for multi-jobsites.
6 Changeable welding position enables to weld various fittings more easily.
7 High accurate and shockproof pressure meter.
8 Separate two-channel timer records time in soaking and cooling phases.
Technology parameter
|
Type |
SDD450 |
|
Materials |
PE, PP, PVDF |
|
Max. range of diameter |
450 mm |
|
Environment Temperature |
－5~45℃ |
|
Power Supply |
～380 V±10％ |
|
Frequency |
50 Hz |
|
Total current |
22.1A |
|
Total power |
8.38kW |
|
Include ： Heating Plate |
5.38 kW |
|
Facing tool Motor |
1.5 kW IP54 |
|
Hydraulic Unit Motor |
1.5 kW IP54 |
When our SDD450 tube welders water poly pipe welding machine butt fusion welding machines hydraulic welds pipe together with data logger, the welding process is in a semi-automatic way, continuous repeat of the welding cycles and automatic control of preset parameters. Data Logger can store up to 1000 welding cycles and sum them into a encrypted EXCEL file. This report can be transferred to a PC/Laptop through a USB port.
