SDD450 Hydraulic Fusion Welding Machine
Application
Suitable for butt welding of plastic pipes and / or fittings made of PE,PP, and PVDF in worksite or workshop.
Feature
a. Extensive production experience: We are specialized in pipe welding machines with an experience more than 20 years. Original in this field in China. Our company has established a long-term stable cooperative relationship with a number of manufacturers.
b. Complete production facilities: Control pressure very well. And pressure can be hold long time to keep good welding quality. European standard and OEM services. All our technology innovation only for one aim--- the best quality, even that means a higher cost and lower production rate.
c. High quality raw material: We mainly choose electrical parts from big good factory.
Like seal ring is from Europe factory . Big different with our Chinese local ring.
d. Strict Physical/Chemical testing procedures: Meeting the requirements of the product design and process, providing reliable testing data.
e. Short Delivery time: If one container 7-10 days. We also stock some standard-sized machines and spare parts.
f. Safe packing: Anti-rust oil be spread on machine before shipping .Each machine is protected with plastic bags. Finally be packed with seaworthy package or in wooden case.
g. Best after-sale service: Over 60% products are sold to the Southeast Asia, Middle East and Europe, and all products are trusted by domestic and foreign customers.
Technolog parameters
|
Type |
SDD450 |
|
|
Materials |
PE, PP, PVDF |
|
|
Max. range of diameter |
450 mm |
|
|
Environment Temperature |
－5~45℃ |
|
|
Power Supply |
～380 V±10％ |
|
|
Frequency |
50 Hz |
|
|
Total current |
22.1A |
|
|
Total power |
8.38kW |
|
|
Include ： Heating Plate |
5.38 kW |
|
|
Facing tool Motor |
1.5 kW IP54 |
|
|
Hydraulic Unit Motor |
1.5 kW IP54 |
|
|
Dielectric resistance |
>1MΩ |
|
|
Undesired sound |
＜70 dB |
|
|
Max. Pressure |
8 MPa |
|
|
Total section of cylinders |
22.37cm2 |
|
|
Volume of oil box |
3L |
|
|
Hydraulic oil |
40～50(kinematic viscosity)mm2/s, 40℃) |
|
|
Max. Temp. of Heating Plate |
270℃ |
|
|
Difference in surface temperature of heating plate |
±5℃ |
|
|
Basic frame |
Size,mm |
1140×750×710 |
|
Weight,kg |
250 |
|
|
Hydraulic unit |
Size,mm |
600×420×380 |
|
Weight,kg |
50 |
|
|
Planing tool |
Size,mm |
790×730×410 |
|
Weight,kg |
46 |
|
|
Heating plate |
Size,mm |
750×650×110 |
|
Weight,kg |
23 |
|
|
Supports |
Size,mm |
445×680×650 |
|
Weight,kg |
25 |
|
|
Total weight,kg |
394 | |
We take pride in being the best when it comes to hydraulic systems. Our systems are known for their incredible ability to hold pressure for long periods of time without any fluctuations or changes. This feature is crucial when it comes to welding, as it ensures that the job is done smoothly and efficiently.
Our hydraulic systems are designed to be reliable and of high quality, ensuring that they perform their tasks seamlessly. We understand the importance of having a hydraulic system that works flawlessly, which is why we invest a lot of time and resources in designing and manufacturing the best systems in the market.
Our systems are highly efficient, enabling our clients to achieve their desired results quickly and with minimal effort. We understand that time is of the essence, which is why we ensure that our systems are not only efficient but also effective.
In conclusion, if you are in need of a hydraulic system for welding purposes, look no further than us. Our systems are top of the line, reliable, and efficient, ensuring that you get the job done right the first time. Choose us for all your hydraulic system needs, and you will not be disappointed!
Our package
Application
FAQ
1. Q:How is your goods quality?
A:We cooperated with many world class companied for many years.Our products received good response from our customers.
2. Q: Do you have the products in stock?
A: Yes.
3. Q: Can I mix different models in one container?
A: Yes, different models can be mixed in one container, but the quantity of each model should not be less than MOQ.
4. Q: How does your factory do regarding quality control?
A: Quality is priority. Sparklewheel People always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.
5. Q:What's your warranty terms?
A: One-two years.
WUXI SHUNDA PLASTIC PIPES WELDING MACHINE CO.,LTD. is the earliest enterprise in China specializing in R&D and production of thermoplastic pipe welding equipment.
We have developed various series plastic pipe welding equipment for different size. Those equipment include manual butt fusion welding machine, hydraulic butt fusion welding machine, workshop fitting welding machine, plastic pipe saw,plastic pipe drainage welder,saddle fusion machine,Radius band saw,Socket welder and customized welding machine.
