Product description
The pipe fusion machine fuses plastic pipes and fittings. These machines are used to prepare and join thermoplastic polymer materials such as "Pipe Fusion Machine" image polypropylene, polyethylene, PVDF and ECTFE pipes. The melting machine heats the ends of the pipes and fittings and presses them together to form a pressure-tight homogeneous joint, thereby forming a continuous pipe system with the same or higher strength as the two melting components.
Technical specifications
Welding ranges: plastic pipes: 200-450mm
(200mm-225mm-250mm-280mm-315mm-355mm-400mm-450mm’)
Ranges of application: PE, PP and PVDF
Working voltage: ～380V ，50Hz
Total power: 8.38 KW, including: planning tool: 1.5 KW, heating plate: 5.38 KW, hydraulic unit motor: 1.5KW
PTFE coated heating plate, adjustable knob for temperature control, difference in heating plate surface temperature ≤±7°.
Environment temperature: －10° ～ 45°;
Electronic count-down timer for heating and cooling time.
Whole machine consists of basic frame, heating plate, planning tool, hydraulic unit and support (for planning tool & heating plate)
Accessories list
Item | Description | Unit | Qty | Remark |
1 | Basic frame | Set | 1 | |
2 | Inserts | Set | 1 | |
3 | Hydraulic Unit | Set | 1 | Include high-pressure oil hose |
4 | Support | Set | 1 | |
5 | Planing tool | Set | 1 | |
6 | Heating plate | Set | 1 | Include connection cable of heating plate |
Attachment with machine | ||||
1 | Tool bag | Set | 1 | |
2 | Blade of planing tool | Set | 1 | |
3 | Open wrench | Pcs | 2 | 22-24，30-32 (for clamps) |
4 | Inner hexagon screw | Pcs | 1 | 8mm(for the screw of clamp) |
5 | Inner hexagon wrench | Set | 1 | 6mm |
Operation instruction | Pcs | 1 | ||
Packing list
Item | Dimension with packing（mm） | N.W（kg） | G.W（kg） | Remark |
1 | 1420×1050×1070 | 249 | 277 | Basic frame ,liner (200-400mm) |
2 | 1000×900×1350 | 128 | 153 | Heating plate, planing tool, support |
3 | 770×480×560 | 43 | 52 | Hydraulic unit |
Total | 3CBM | 420 | 482 |
Features
Consists of basic frame, hydraulic unit, planing tool, heating plate, support for planing tool & heating plate, and optional parts.
Removable PTFE coated heating plate with high accurate temperature control system;
Electrical planning tool with safety limit switch to avoid starting unexpectedly.(optional)
Be made of lightweight and high strength material; Specially designed with a clamp opening angle of 45°
Low starting pressure ensures reliable welding quality of small pipes.
Changeable welding position enables to weld various fittings more easily.
Separate two-channel timer shows time in soaking and cooling phases. Give a alarm when timing over.
High-accurate and shockproof pressure meter indicates clearer readings.
Digital pressure meter is installed on machines
