HDPE plastic pipe hot melt hydraulic butt fusion welding machine

Application

Suitable for butt welding of plastic pipes and / or fittings made of PE,PP, and PVDF in worksite or workshop.

Features

Removable PTFE coated heating plate with separate temperature control system.

Electrical planning tool;

Be made of lightweight and high strength material; simple structure, small and delicate user friendly;

Low starting pressure ensures reliable welding quality of small pipes;

Separate two-channel timer shows time in soaking and cooling phases;

High-accurate and shockproof pressure meter in indicates clear readings.

Adding four wheels, easy to move. Also it can be linked with truck.

QQ20220422082610

Technology parameters

Type	SDD500
Materials	PE, PP, PVDF
Max. range of diameter	500 mm
Environment Temperature	－5~45℃
Power Supply	～380 V±10％
Frequency	50 Hz
Total current	32.5 A
Total power	12.35kW
Include ： Heating Plate	9.35 kW
Facing tool Motor	1.5 kW IP54
Hydraulic Unit Motor	1.5 kW IP54
Dielectric resistance	>1MΩ
Undesired sound	＜70 dB
Max. Pressure	8 MPa
Total section of cylinders	23.06cm2
Volume of oil box	3L
Hydraulic oil	40～50(kinematic viscosity)mm2/s, 40℃)
Undesired sound	＜70 dB
Max. Temp. of Heating Plate	270℃
Difference in surface temperature of heating plate	±5℃
Basic frame	Size,mm	1570×900×930
Weight,kg	300
Hydraulic unit	Size,mm	700×520×490
Weight,kg	76
Planing tool	Size,mm	840×280×1300
Weight,kg	50
Heating plate	Size,mm	990×70×960
Weight,kg	30
Supports	Size,mm	800×650×770
Weight,kg	30
Total weight,kg	486
