Operating steps of electric fusion welding machine

1. Prepare the electric fusion welding machine and the PE pipes and fittings that need to be welded.
2. Remove the oxide layer on the insertion end of the PE pipe and insert it into the electrofusion pipe fitting. It is better to insert the pipe fittings easily. Do not force the pipes into the pipe fittings. If the pipe fittings are inserted too tightly during welding, the expansion process of the PE material after heating can easily cause the displacement of the electric heating, thereby changing the temperature change caused by heating. It is easy to cause local heating temperature to be too high, causing welding smoke and other failures. In special cases, if the pipe is not inserted into the fitting in a straight line, that is to say, the pipe and the fitting are not coaxial, in this case, a special straightener is needed to fix the pipe and fitting to reduce the stress of the pipe being inserted into the fitting.
3. When ready, insert the output electrode of the electric fusion welder into the electrode post of the pipe fitting.
4. Start the electrofusion welding machine, scan the barcode or enter the voltage and time parameters required to weld and start welding.
5. After the welding countdown is over, the output cable can be removed without affecting the cooling and welding of the pipe and start preparing for the next welding.
